پګمنټ وایلیټ 23-کوریمکس وایلیټ RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

د pigment وایلیټ 23 تخنیکي پیرامیټونه

د رنګ فهرست.سور رنګ وایل 23
د محصول نومکوریمکس وایلیټ RLS
د محصول کټګورۍارګانیک رنګ
د ر Lightا ګړندۍ (پوښ)7
د ګرمۍ مقاومت (پوښ)200
د ر Lightا ګړندۍ (پلاستيکي)7
د تودوخې مقاومت (پلاستیک)250
رنګ
رنګ-وایلیټ-23-رنګ
د رنګ توزیعپی وی

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

برخی:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

غوښتنلیک :

د موټرو پینټونو ، معمارۍ کوټینګونو ، کویل کوټینګونو ، صنعتي رنګونو ، پاؤډ کوچینګونو ، د چاپ کولو پاسټونه ، PVC ، ربړ ، PS ، PP ، PE ، PU ، د آفسیټ رنګونه ، د اوبو پر اساس رنګونه ، محلول رنګونه ، UV inks لپاره وړاندیز شوی.

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
-------------------------------------------------- ---------------

اړوند معلومات

فزیکي او کیمیاوي ملکیتونه:
رنګ یا ر lightا: نیلي ارغواني
اړوند کثافت: 1.40-1.60
د بلک کثافت / (Lb / gal): 11.7-13.3
د خټکي ټکی / ℃: 430-455
د اوسط ذرې اندازه / μ م: 0.04-0.07
د ذرې شکل: کیوبک / راډ
ځانګړې سطحه ساحه / (m2 / g): 45-102
د پی اچ ارزښت / (10٪ سلورري): 6.2

د محصول کارول:د رنګ ورایټ 23 په عمده ډول د رنګه رنګونو ، رنګونو ، ربړو او پلاسټیکونو لپاره او همدارنګه د مصنوعي فایبرونو رنګ کولو لپاره کارول کیږي
د pigment 124 ډوله سوداګریزو فورمولونو برانڈونه شتون لري. کاربازازین د قوي او غیر معمولي غوښتنلیک سره نیلي نیلي وایل ډول دی ، او د مونوالیټ وایلیټ RN مشخص سطحي ساحه 74m2 / g ده. دا په پراخه کچه په بیلابیلو برخو کې کارول کیږي لکه کوټ ، رنګ چاپ ، پلاستيک او پوښاک چاپ او رنګ ورکول. دا د رنګ کولو پرمهال وارنش ته ښه ګړندی لري. دا د هوا وچولو پینټ ، د موټرو پینټ OEM او بیکینګ پینټ لپاره کارول کیدی شي ، په ځانګړي توګه د CuPc ټونر او قوي سپک ټون سره د لیټیکس پینټ لپاره. دا د پلاستيک رنګ کولو لپاره کارول کیدی شي ، په ګولیوفینین او د لوړ رنګ ساتلو کې د تودوخې مقاومت 280 with سره (د 1 / 3SD سره د ایچ ډی پی ای لپاره یوازې د 0.07 pig روغن رژیم ته اړتیا ده)؛ دا د پالیسټر او PE رنګ کولو لپاره هم کارول کیدی شي.

د ترکیب اصل: کاربازول د خامو موادو په توګه کارول کیږي ، او N-Eyation د مرحلې السرسي کتلست په موجودیت کې د نورمال فشار لاندې ترسره کیږي ، او د نایټریشن عکس العمل او د کمولو عکس العمل د 2-امینو - N-اتیل کاربازول ترکیب لپاره ترسره کیږي؛ د 3،5،6 ټیټراکلورپاراواکین (کلورانیل) د رګ او بندیدو عکس العمل سره مخ شوی ، فلټر شوی ، د اوبو سره مینځل شوی ، او وچ شوی کاربازول وایل ترلاسه کولو لپاره وچ شوی؛ په نهایت کې ، د CI pigment وایلیټ 23 ترلاسه کولو لپاره په غوټیدو یا ټکولو سره د عام pigmentation درملنه.

عرفان :Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

مالیکول جوړښت:رنګ-وایلیټ - 23 - مالیکول - جوړښت
